Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (ST4300USB3)
Port Function
1Power LED • is receiving power.Solid: Hub
2USB-A Ports (4) • Used to connect USB devices to the .Hub
Port Function
3Power Port
• Used with the , to power the Power Adapter
Hub.
4USB-B Port (Host)
• Used to connect the to the Host Computer
Hub.
Requirements
For the latest requirements, please visit , www.startech.com/ST4300USB3 www.startech.
com/ST4300USB3EU, www.startech.com/ST4300USB3GBor
4 Port Black SuperSpeed USB 3.0 Hub
1
Installation
1. Connect the included power adapter to the USB hub. The power LED should light
up solid. Supplying external power is optional, however to ensure each USB port is
fully powered, connecting external power is recommended.
2. Connect the USB cable from the USB hub (type B port) to the host computer system.
NOTE: If connected to a USB 2.0 host port, the hub will only operate at USB 2.0 speeds.
3. The operating system should detect the hub immediately and automatically install
it.
4. Once installation is complete, USB 1.x/2.0/3.0 devices should be able to be
connected to the hub and recognized.
Specications
Bus Interface USB 3.0
Number of Ports 4
Chipset ID VLI VL810
Connectors
• USB-A x 4
• USB-B x 1
• DC Power x 1
LEDs Power x 1
Maximum Data Transfer Rate USB 3.0L 5 Gbps
Enclosure Material Plastic
Power Adapter 5VDC, 2000mA, type M plug
Operating Temperature 0°C~55°C (32°F~131°F)
Storage Temperature -20°C~85°C (-4°F~185°F)
Humidity 5%~95% RH
Dimensions 152.0mm x 59.6mm x 23.5mm
Weight 480g
2
3
4
Probleemoplossing StarTech.com ST4300USB3GB
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 55 g |
| Breedte: | 68 mm |
| Diepte: | 95 mm |
| Hoogte: | 23 mm |
| Gewicht verpakking: | 440 g |
| Breedte verpakking: | 150 mm |
| Diepte verpakking: | 210 mm |
| Hoogte verpakking: | 80 mm |
| Gebruikershandleiding: | Ja |
| Materiaal behuizing: | Kunststof |
| LED-indicatoren: | Stroom |
| Type stroombron: | AC |
| Meegeleverde kabels: | USB |
| Geïntegreerde geheugenkaartlezer: | Nee |
| Inclusief AC-adapter: | Ja |
| Certificering: | CE, FCC, RoHS |
| Plug and play: | Ja |
| Ingangsspanning: | 100 - 240 V |
| Temperatuur bij opslag: | -20 - 60 °C |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 4 |
| Output current: | 2 A |
| Spanning: | 5 V |
| Hostinterface: | USB 2.0 Type-B |
| Chipset: | VIA/VLI - VL811+ |
| Overdrachtssnelheid: | 5000 Mbit/s |
| Stroomverbruik (typisch): | 10 W |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 85 procent |
| Code geharmoniseerd systeem (HS): | 84719000 |
| Aantal poorten: | 4 |
| Hub-interfaces: | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
