Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 18, 2024 4:58 PM
Product ID
5G16AINDS-USB-A-HUB
16-Port Industrial USB 3.2 Gen 1 Hub - ESD and Surge Protection - Dual Host
Component Function
1
DC Power Input
• Connect a +7~24 V DC Power Source
• 120W or higher recommended for maximum
power performance
2
DC 2-Wire Terminal Block Power
Input
• Connect a +7~24 V DC Power Source
• 120W or Higher Recommended for maximum
power performance
3
Power LED
• Indicates if the USB Hub is receiving power from either
a USB Host or a DC Power Source
• Solid Green - Receiving Power
• O - Not Receiving Power
4
USB Host Port A
(Screw Locking, USB-B)
• Connect to a USB-A Port on a Host Computer
• USB 3.2 Gen 1 (5 Gbps)
5
USB Host Port B
(Screw Locking, USB-B)
• Connect to a USB-A Port on a Host Computer
• USB 3.2 Gen 1 (5 Gbps)
Product Diagram
1
2 3
7
5
6
Host Device Port Switch
• Switches Hub Connectivity between USB Host Ports
A & B
7
USB Host Selection LEDs
• Indicates which Host Device is currently selected
• Solid Green - Host Device Selected
• O - Host Device Not Selected
8
16x USB Data/Charge Ports
(Screw Locking, USB-A)
• Connect USB Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• BC 1.2 Charging with 5V 2.0A Maximum or 1.5A
Simultaneous
9
1U Mounting Brackets
• Mount the USB Hub into 1U of Rack Space
• Mount the USB Hub to a wall or the side/underside of
a Desk
4
6
8
9
Package Contents
• USB Hub x 1
• 10 ft [3 m] USB-A to USB-B Cable x 1
• Terminal Block Connector (Attached)
• DIN Rail Mounting Brackets (with Mounting Screws) x 2
• Quick-Start Guide x 1
* Product may vary from image
