Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: October 12, 2023
Product ID
PR12GIP-NETWORK-CARD
Port/LED/Connector Function
1Bracket
• Secures the card to the Host Computer Case
• The comes pre-installedFull Prole Bracket
• The is included Low Prole Bracket
2
Power Over Ethernet
(PoE) LED Indicator
• Solid Green: PoE has been negotiated and power is
being supplied to the Powered Device
• O: No power output has been negotiated
3Ethernet Port
• Connect an to the Ethernet Cable Network Card
• Supports 2.5Gbps, 1Gbps, 100Mbps, and 10Mbps
• Supports and IEEE 802.3at IEEE 802.3af
• Right LED Indicator Link Speed is
• Solid Green: 2.5Gbps
• Solid Amber: 1Gbps
• O: 10/100Mbps
• Left LED Indicator Link Status is
• Solid Green: Active link
• Flashing Green: Activity
1-Port PCIe 2.5GBase-T Ethernet PoE Network Adapter Card - Intel
4PCIe 2.0 p1-x1 Connector • Insert into a on the PCI Express Slot Host Computer
5
SATA Power
Connector
• Connect from the SATA Power Host Computer’s
Power Supply
• Required to enable Power over Ethernet (PoE)
Package Contents
• Network Card x 1
• Low Prole Bracket x 1
• Quick-Start Guide x 1
Requirements
For the latest requirements, please visit: www.StarTech.com/PR12GIP-NETWORK-CARD
• Host Computer with an available PCI Express 2.0 or greater slot (x1, x4, x8, or x16)
Installation
Install the PCI Express Card
WARNING! Static Electricity PCI Express Cardscan severely damage . Ensure that
you are adequately before you open your or touch Grounded Host Computer Case
the . You should wear an or use anPCI Express Card Anti-Static Strap Anti-Static
Mat Anti-Static Strap when installing any Host Computer component. If an isn’t
available, discharge any built-up static electricity by touching a large Grounded
Metal Surface PCI Express Card for several seconds. Only handle the by its edges and
don’t touch the gold connectors.
1. Turn o the and any that are connected to it Host Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the back of the .Power Cable Host Computer
3. Disconnect any that are connected to the .Peripheral Devices Host Computer
4. Remove the from the . Cover Host Computer Case
Note: Consult the documentation that came with the for details Host Computer
about doing this safely.
5. Locate an open and remove the corresponding PCI Express Slot Slot Cover Plate
from the back of the . Host Computer Case
4
1
2
3
5
Probleemoplossing StarTech.com PR12GIP-NETWORK-CARD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 62 g |
| Breedte: | 54 mm |
| Diepte: | 119 mm |
| Hoogte: | 16 mm |
| Gewicht verpakking: | 70 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| LED-indicatoren: | Ja |
| Connectiviteitstechnologie: | Bedraad |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Interface: | Ethernet |
| Duurzaamheidscertificaten: | RoHS |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000,2500 Mbit/s |
| Netwerkstandaard: | IEEE 1588, IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u |
| Temperatuur bij opslag: | -10 - 70 °C |
| Intern: | Ja |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ja |
| Spanning: | 48 V |
| Snelle installatiehandleiding: | Ja |
| Hostinterface: | PCI Express |
| Andere ondersteundende systemen: | VMware vSphere ESXi |
| Maximale overdrachtssnelheid van gegevens: | 2500 Mbit/s |
| Quality of Service (QoS): | Ja |
| Ondersteunde server operating systems: | Windows Server 2019, Windows Server 2022 |
| Chipset: | Intel I225-V |
| Component voor: | Pc/server |
| Wake-on-LAN: | Ja |
| Bedrijfstemperatuur (T-T): | 0 - 55 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 90 procent |
| Hoeveelheid Power over Ethernet (PoE) ports: | 1 |
| PCI versie: | 2.0 |
| Aantal SATA power connectors: | 1 |
