Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: February 2, 2023 11:44 AM
Product Diagram (TB310G2)
Front View
Component Function
1
Thunderbolt 3 Host
Port
• Connect to a Thunderbolt 3 compatible Host
Computer
2 LED Indicator
• Solid Blue = Indicates if the Thunderbolt 3 to
Ethernet Network Adapter is linked to the Host
Computer
Rear View
Thunderbolt 3 to 10GBase-T Ethernet Network Adapter
Component Function
1 LED Indicators
• Left LED Indicator is Link Speed
• Solid Green = 10 Gbps
• Solid Amber =
5 Gbps, 2.5 Gbps, 1 Gbps, and 100 Mbps
• Right LED Indicator is Link Status
• Solid Green = Active link
• Flashing Green = Activity
2 Ethernet Port
• Connect an Ethernet Cable
Use Cat6 or better cabling for 10 Gbps speeds
Package Contents
• Ethernet Network Adapter x 1
• 27.5 in (70 cm) Thunderbolt 3 Cable x 1
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.startech.com/TB310G2
• Thunderbolt 3 compatible host computer
• Ethernet Cable
Operation
Thunderbolt 3 Host
1. Connect a Thunderbolt 3 Cable (included) to the Thunderbolt 3 Host Port on the
front of the Thunderbolt 3 Ethernet Network Adapter and to a Thunderbolt 3
Port on the Host Computer.
Note: Driver installation is not required.
Windows Thunderbolt Approval Pop-Up
When the Thunderbolt 3 Ethernet Network Adapter is connected to a Host
Computer that is running a Windows operating system a pop-up message will appear.
To use the Thunderbolt 3 Ethernet Network Adapter, complete the following:
1. In the New Thunderbolt devices have been connected pop-up message, click OK.
2. In the User Account Control pop-up message, click Yes.
1
1
2
2
*Product may vary from image
Probleemoplossing StarTech.com TB310G2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Grijs |
| Gewicht: | 500 g |
| Breedte: | 108 mm |
| Diepte: | 75 mm |
| Hoogte: | 29 mm |
| Snoerlengte: | 0.7 m |
| Gewicht verpakking: | 700 g |
| Breedte verpakking: | 170 mm |
| Diepte verpakking: | 134 mm |
| Hoogte verpakking: | 74 mm |
| Materiaal behuizing: | Aluminium |
| LED-indicatoren: | Activity, Link |
| Connectiviteitstechnologie: | Bedraad |
| Ethernet LAN: | Ja |
| Meegeleverde kabels: | Thunderbolt |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Interface: | Ethernet |
| Ethernet LAN, data-overdrachtsnelheden: | 100,1000,2500,5000,10000 Mbit/s |
| Bekabelingstechnologie: | 10GBase-T |
| Netwerkstandaard: | IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u |
| Intern: | Nee |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Snelle installatiehandleiding: | Ja |
| Ethernet interface type: | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Hostinterface: | Thunderbolt 3 |
| Maximale overdrachtssnelheid van gegevens: | 40000 Mbit/s |
| Jumbo Frames ondersteuning: | Ja |
| Full duplex: | Ja |
| Component voor: | PC |
| (Buitenste) hoofdverpakking hoogte: | 313 mm |
| (Buitenste) hoofdverpakking breedte: | 318 mm |
| (Buitenste) hoofdverpakking lengte: | 395 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 20 stuk(s) |
| Auto MDIX IEEE: | Ja |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Jumbo frames: | 16000 |
