StarTech.com USB32DP24K60 Handleiding
Hier is de StarTech.com USB32DP24K60 (Netwerkkaart/adapter) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 0.3 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 11/17/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/USB32DP24K60
Package contents
Requirements
• Two DisplayPort monitors with cabling
• A computer system with:
• An available USB 3.0 port
• Windows® 10, 8.1, 8 or 7
• macOS High Sierra (10.13), Sierra (10.12), El Capitan (10.11),
Yosemite (10.10)
Operating system requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/USB32DP24K60.
USB32DP24K60
USB 3.0 to Dual DisplayPort Adapter - 4K 60Hz
*actual product may vary from photos
1 x USB video adapter
1 x quick-start guide
Product overview
Integrated USB 3.0
input cable
DisplayPort
output port #1
Notes:
• You may need to restart your computer during the software
installation process. Be sure to save any unsaved material before
you install the software.
• If you’re running Windows 7, macOS 10.10 or macOS 10.1, ensure
the USB video adapter is not connected to your computer until
after driver installation.
1. If you’re running Windows 7, macOS 10.10 or macOS 10.11,
download the latest software from the StarTech.com website:
http://www.StarTech.com/USB32DP24K60
Note: If you’re running Windows 8 (or later), or macOS 10.12
(or later) proceed to step 5.
2. The software will be compressed in a .zip folder. Extract the
contents of the folder to a location on your computer that’s easy
to access, such as your or Desktop Downloads folder.
3. Open the folder that corresponds with your operating system.
If you’re running Windows, launch the (exe) le. If you’re Setup
running macOS, launch the (dmg) le.DisplayLink Installer
4. Follow the on-screen prompts to complete the installation, and if
instructed to do so, restart your computer.
5. Connect a DisplayPort cable to each of the adapter’s DisplayPort
output ports and to your DisplayPort monitors.
6. Once your computer has restarted, connect the Integrated USB
3.0 input cable to a USB port on your computer.
Important notes:
If connecting multiple USB video adapters or docking stations
to a single computer:
• This USB video adapter uses a DisplayLink family chipset.
If you’re connecting this device to a computer along with
additional USB video adapters or docking stations, avoid using
devices with dierent family chipsets, such as Trigger or Fresco
Logic®.
• To connect multiple USB display adapters to the same
computer, you don’t need to install any additional drivers.
Repeat steps 5 through 6 for each video adapter.
• You may be prompted to restart your computer after
connecting each USB video adapter.
Installation
DisplayPort
output port #2
If you’re running Windows 7, macOS 10.10 or
macOS 10.11, you must ensure the latest drivers
from the StarTech.com website are installed before
connecting the USB video adapter to the computer.
If you’re running Windows 8 macOS (or later), or
10.12 (or later), you can utilize an internet
connection to automatically install the latest drivers
as soon as the USB video adapter is connected to the
computer.
Probleemoplossing StarTech.com USB32DP24K60
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 70 g |
| Breedte: | 60 mm |
| Diepte: | 80 mm |
| Hoogte: | 16 mm |
| Gewicht verpakking: | 72 g |
| Breedte verpakking: | 45 mm |
| Diepte verpakking: | 175 mm |
| Hoogte verpakking: | 134 mm |
| Materiaal behuizing: | Kunststof |
| USB-connectortype: | USB Type-A |
| Maximum resolutie: | 4096 x 2160 Pixels |
| Certificering: | CE, FCC, REACH |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Maximale videoresolutie: | 4096 x 2160 Pixels |
| Intern geheugen: | 8 GB |
| Intern geheugentype: | DDR3L |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -20 - 70 °C |
| Compatibele besturingssystemen: | Windows® 2000, XP, Vista, 7, 8, 8.1, 10\nMacOS® 10.6 to 10.13\nUbuntu 14.04, 16.04\nChrome OS v55+ |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura |
| Mac-compatibiliteit: | Ja |
| Audio-uitgangskanalen: | 2.0 kanalen |
| Ondersteunt Linux: | Ubuntu 14.04, Ubuntu 16.04, Y |
| Snelle installatiehandleiding: | Ja |
| Stroomvoorziening via USB: | Ja |
| Hostinterface: | USB 3.2 Gen 1 (3.1 Gen 1) |
| Andere ondersteundende systemen: | ChromeOS |
| Aantal displays ondersteund: | 2 |
| Chipset: | DisplayLink - DL-6950 |
| USB kabel lengte: | 0.3 m |
| (Buitenste) hoofdverpakking hoogte: | 310 mm |
| (Buitenste) hoofdverpakking breedte: | 330 mm |
| (Buitenste) hoofdverpakking lengte: | 358 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 40 stuk(s) |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 90 procent |
| Code geharmoniseerd systeem (HS): | 84733020 |
| RAM minimum: | 4 GB |
| HDMI-uitgang: | Nee |
| Ondersteunende oplossingen: | 4096x2160, 3840×2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720, 1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640x480 |
| Output interface: | 2 x DisplayPort |
| Geslacht USB-connector: | Mannelijk |
| Minimale processorsnelheid: | 2.4 GHz |
| DisplayPort-uitgang: | Ja |
| DVI-uitgang: | Nee |
| Refreshrate bij maximale resolutie: | 60 Hz |
| USB pass-through: | Nee |
