Quick-start guide
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 11/27/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/US1GA30SXSC
Package contents
• 1 x network adapter
• 1 x quick-start guide
Requirements
• USB-enabled computer with an available USB 3.0 port
• Any of the following operating systems:
• Microsoft Windows® 10, 8/8.1, 7
• Microsoft Windows Server® 2012, 2008, 2003
• macOS High Sierra (10.13), Sierra (10.12) El Capitan (10.11),
Yosemite (10.10), Mavericks (10.9), Mountain Lion (10.8)
• Linux® kernel 3.5 to 4.11.x, LTS versions only
Operating system requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/US1GA30SXSC.
US1GA30SXSC
USB 3.0 to Gigabit Ethernet Fiber Optic Network Adapter - 1000Base-SX SC
*actual product may vary from photos
Product diagram
Link and activity LED
Built-in USB 3.0
cable
Installation
Notes: You may need to restart your computer during the software
installation process. Be sure to save any unsaved material before you
install the software.
1. Connect a multimode SC ber cable to the network adapter’s
Fiber optic SC port and to your ber network.
2. Connect the built-in USB 3.0 cable on the network adapter to a
USB port on your computer.
Note: If the driver for the network adapter installs automatically,
the installation is complete. If the driver does not install
automatically, you’ll need to manually install the driver. Follow the
instructions below for your specic operating system.
Windows
1. If the Found New Hardware dialog box appears on your screen,
close the dialog box or click Cancel.
Note: Once the network adapter is connected to the computer,
it will load a CD-ROM device that contains an executable le that
you can use to install the driver.
2. After the CD-ROM device nishes loading, run the installation le.
3. Complete the on-screen instructions to nish the installation.
Note: You can also download the latest software from the
StarTech.com website,
www.StarTech.com/US1GA30SXSC.
macOS
1. Download the latest macOS drivers from the StarTech.com
website,
www.StarTech.com/US1GA30SXSC.
2. The drivers will be compressed in a .zip folder, extract the
contents of that folder to a location on your computer that’s easy
to access, such as your . Desktop
3. Double-click the appropriate installer le for the version of macOS
that you’re running, and follow the on-screen instructions to
complete the installation.
Power LED
Fiber optic SC
port
Probleemoplossing StarTech.com US1GA30SXSC
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 100 g |
| Breedte: | 55 mm |
| Diepte: | 260 mm |
| Hoogte: | 20 mm |
| Snoerlengte: | 0.195 m |
| Gewicht verpakking: | 54 g |
| Breedte verpakking: | 170 mm |
| Diepte verpakking: | 142 mm |
| Hoogte verpakking: | 30 mm |
| LED-indicatoren: | Activity, Link, Power |
| Connectiviteitstechnologie: | Bedraad |
| Snelstartgids: | Ja |
| Interface: | Fiber |
| Duurzaamheidscertificaten: | CE, RoHS |
| Plug and play: | Ja |
| Netwerkstandaard: | IEEE 802.1Q, IEEE 802.3z |
| Temperatuur bij opslag: | -10 - 70 °C |
| Intern: | Nee |
| Ondersteunt Mac-besturingssysteem: | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ja |
| Stroomvoorziening via USB: | Ja |
| Hostinterface: | USB |
| Maximale overdrachtssnelheid van gegevens: | 1000 Mbit/s |
| Maximale afstand: | 550 m |
| Ondersteunde server operating systems: | Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
| Chipset: | Realtek - RTL8153-VB-CG, Microsemi - VSC8211XVW |
| (Buitenste) hoofdverpakking hoogte: | 355 mm |
| (Buitenste) hoofdverpakking breedte: | 300 mm |
| (Buitenste) hoofdverpakking lengte: | 590 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 80 stuk(s) |
| Wake-on-LAN: | Ja |
| Bedrijfstemperatuur (T-T): | 0 - 60 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 90 procent |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Vezel-optische connector: | SC |
| Fibre channel-poorten: | 1 |
| PCI versie: | 3.0 |
| Fiber ethernet cabling technologie: | 1000BASE‑SX |
| VLAN-tagging: | Ja |
