Pagina 1/2
S-Video and Composite to HDMI
Converter
V2V-AV2H-01
www.smartavi.com
Installation
Manual
Whats in the Box?
PART NO. QTY DESCRIPTION
V2V-AV2H-01 1 SVideo, Composite Video and Audio to HDMI
Converter
PS5VDC2A 1 5 Volt 2 Amp Power Supply
Technical Specications
OTHER
Power External 100-240 VAC/5VDC2A @10W
Dimensions 5.25 in W x 3.5 in H x 1 in D
Weight 0.71 lb
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
© Copyright 2012 SmartAVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
11651 Vanowen St. North Hollywood, CA 91605
Tel: (818) 503-6200 Fax: (818) 503-6208
http://www.SmartAVI.com
Rack Mountable Option
Our SmartRack is the perfect solution to allow
virtually all SmartAVI devices to be custom mounted
in a standard 19” server rack. The SmartRack is fully
adjustable and can secure/organize several devices.
HDMI VIDEO
Format HDMI 1.3b [Deep Color, xvYcc color space
supported]
DVI Compliance Single-link DVI-D 1.1
HDCP Compliance 1.0/1.1
Video Bandwidth Single-link 340MHz [10.2Gbps]
Resolution 480i,480p,720i,720p,1080i,1080p
Output Interface (1) HDMI[7.1ch audio & video]
Connector Type A[19-pin female]
Maximum Distance 25 ft.
COMPOSITE VIDEO
Input Format NTSC/PAL/SECAM
Output Formats NTSC/PAL/SECAM
Resolution 800 x 600, 1024 x 768,
up to 1280 x 1024@60Hz
Input Interface (3) RCA Female
V2V FAMILY
AUDIO
Signal Type Stereo Unbalanced
Ouput Interface Left/Right RCA (Female)
S-VIDEO
Input Format NTSC/PAL/SECAM
Resolution 800 x 600, 1024 x 768,
up to 1280 x 1024@60Hz
Input Interface (1) S-Video Female

Probleemoplossing Smart-AVI V2V-AV2H-01

Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp


Specificaties

Soort: AV-zender & ontvanger
Ondersteunde video-modi: 1080i, 1080p, 480i, 480p, 720i, 720p
Maximum resolutie: 1280 x 1024 Pixels
S-Video ingang: 1
Formaat analoog signaal: NTSC, PAL, SECAM
Aansluiting voor netstroomadapter: Ja
HDMI versie: 1.3
Ondersteunde grafische resoluties: 1024 x 768 (XGA), 800 x 600 (SVGA)
Temperatuur bij opslag: -20 - 85 °C
DVI output ports: 1
Aantal HDMI-uitgangen: 1
AC-ingangsspanning: 100-240 V
Stroomverbruik (typisch): 10 W
Bedrijfstemperatuur (T-T): 0 - 55 °C
Relatieve vochtigheid in bedrijf (V-V): 0 - 95 procent
