1000 Mbps Gigabit Single Mode Fiber Media Converter LC 40 km
StarTech ID: ET1000S40LC2
The ET1000S40LC2 1000 Mbps Gigabit Single-Mode Fiber Media Converter (LC, 40 km) enables you to extend
a Gigabit Ethernet network over single-mode fiber, at distances up to 40km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments
over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal
network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the
Ethernet to LC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal
configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U
Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Provides connectivity to a user or network segment that is in an isolated area of a large complex or in
another building altogether
Perfect for secure connections required by government agencies where EMI is not acceptable
Connect traffic control/monitoring systems at extreme distances to the main office
Extend network connectivity to remote areas of stadiums, auditoriums or other venues
Converts 1000Base-LX fiber optic signals to 1000Base-T Ethernet over single mode fiber cable
Probleemoplossing StarTech.com ET1000S40LC2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 620 g |
| Gewicht verpakking: | 754 g |
| Breedte verpakking: | 205 mm |
| Diepte verpakking: | 138 mm |
| Hoogte verpakking: | 89 mm |
| Gebruikershandleiding: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Certificering: | CE, FCC |
| Aansluiting voor netstroomadapter: | Ja |
| Duurzaamheidscertificaten: | RoHS |
| Plug and play: | Ja |
| Ethernet LAN, data-overdrachtsnelheden: | 10,100,1000 Mbit/s |
| Temperatuur bij opslag: | -10 - 70 °C |
| Intern: | Nee |
| Golflengte: | 1310 nm |
| Externe adapter: | Ja |
| Output current: | 1 A |
| Spanning: | 12 V |
| Ethernet interface type: | Gigabit Ethernet |
| Mean time between failures (MTBF): | 65000 uur |
| Maximale overdrachtssnelheid van gegevens: | 2000 Mbit/s |
| Auto MDI/MDI-X: | Ja |
| Afmetingen (B x D x H): | 95 x 160 x 20 mm |
| Full duplex: | Ja |
| Maximaal bereik: | 40000 m |
| Bedrijfstemperatuur (T-T): | 0 - 60 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Vezel-optische connector: | LC |
| Converter input interface: | 1000Base-T |
| Duplex systeem: | Full, Half |
| Converter output interface: | 1000Base-LX, 1000Base-SX |
| Fibre channel-poorten: | 1 |
| Draad modus structuur: | Single-mode |
