StarTech.com ECREAD Handleiding
Hier is de StarTech.com ECREAD (Geheugenkaartlezer) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 0.3 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
Thank you for purchasing a StarTech.com ExpressCard Memory Card Reader. Providing convenient access to popular media/
memory cards from a notebook computer, this 12-in-1 media/memory card reader is an ideal selection for accessing data such as
digital photos, multimedia and more, while ensuring cost-effective operation.
Features
Installs into ExpressCard 34mm or 54mm slots•
Supports high speed and high capacity memory cards•
Hot swappable, plug and play operation•
USB 2.0 transfer rate up to 480 Mbps•
Package Contents
1 x 12-in-1 Card Reader•
1 x Instruction Manual•
Please note: It is advisable to remove all possible static discharge potential from any objects that the
ExpressCard may come in contact with before installation. This can be accomplished by touching a grounded
metal object, prior to insertion
Locate an unused ExpressCard slot on the host computer.1.
Insert ECREAD into the available ExpressCard slot. Since this card is hot-pluggable, this can be performed while the 2.
computer is on or off. Once the card has been inserted, ensure the computer is powered, to proceed with installation
Windows will detect that the card has been inserted, and will prompt for driver installation. Because Windows natively supports 3.
this device, there is no need for additional driver installation. Please follow the on-screen instructions to complete installation.
Once the driver has been installed, the operating system will notify you that your new hardware is ready for use.
In Microsoft® Windows
When the card reader is connected to the computer but contains no memory card, a removable disk icon with an assigned drive
letter will appear in My Computer. Once a card is inserted, the name of the removable disk will change accordingly based on the
media type.
To access the inserted media, simply click on the icon representing the drive location.
Please see reverse for further instruction and product specifications
Probleemoplossing StarTech.com ECREAD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 16 g |
| Gewicht verpakking: | 40 (tbc) g |
| Breedte verpakking: | 14 mm |
| Diepte verpakking: | 108 mm |
| Hoogte verpakking: | 160 mm |
| Compatibele geheugenkaarten: | Memory Stick (MS), MS PRO, MMC, SD, xD |
| Intern: | Ja |
| Compatibele besturingssystemen: | Windows 2000/ME/XP/Vista/Mac OSX |
| Soort aansluiting: | ExpressCard |
| Afmetingen (B x D x H): | 33 x 78 x 5 mm |
| Lengte van de verpakking: | 108.00 mm |
